Engine and Transmission

Displacement: 999cc
Engine Type: liquid-cooled inline four-cylinder
Bore and Stroke: 76mm x 55.1mm
Compression Ratio: 12.3:1
Valve Train: DOHC; four valves per cylinder
Induction: Dual Stage Fuel Injection (DSFI)
Ignition: Computer-controlled digital transistorized with three-dimensional mapping
Transmission: Close-ratio six-speed
Final Drive: #530 O-ring - sealed chain

Chassis and Dimensions

Suspension Front: 43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability; 4.3 inches travel
Rear: Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability; 5.4 inches travel
Brakes Front: Dual radial-mounted four-piston calipers with full-floating 320mm discs
Rear: Single 220mm disc
CBR1000RR ABS: Honda electronic Combined ABS
Tires Front: 120/70ZR-17 radial
Rear: 190/50ZR-17 radial
Wheelbase: 55.4 inches
Rake (Caster Angle): 23.3o
Trail:     96.2mm (3.8 inches)
Seat Height: 32.3 inches
Fuel Capacity: 4.7 gallons, including 1.06-gallon reserve
Curb Weight*: 439 pounds (461.7 pounds CBR1000RR ABS)
