FRAME
ONE-TWENTY LITE V

FORK
Marzocchi Bomber Z2
Air
130mm suspension travel
Tapered
44mm fork offset
platform
29x2.6" max wheelsize

SHOCK
Marzocchi Bomber inline

BRAKES
Shimano Deore M6120 / Shimano Deore M6100
4 piston
2 piston

ROTORS
Shimano RT30
203mm
180mm

HEADSET
Acros ICR MERIDA EXTERNAL neck

HANDLEBAR
MERIDA COMP TR
material: aluminium
780mm width
20mm rise

HANDLEBAR STEM
MERIDA EXPERT eTRII
material: aluminium
35mm diameter
0° stem angle
40 mm

GRIP
MERIDA COMP EC

DERAILLEUR (R)
Shimano Deore M6100

SHIFTERS
Shimano SL-MT500-IL / Shimano Deore M6100

SEAT POST
MERIDA EXPERT TR II
34.9mm diameter
0mm setback
XSHORT/SHORT: 150mm travel seatpost - MID: 170mm travel seatpost - LONG, XLONG: 200mm travel seatpost

SEAT CLAMP
MERIDA EXPERT

SADDLE
MERIDA COMP SL

CHAIN
KMC X12

CRANK
Shimano Deore MT512
32 teeth
170 mm for all sizes

FREEWHEEL
Shimano Deore M6100
10-51 teeth
12 speed

BOTTOM BRACKET
Shimano BB-MT-501

HUBS
Shimano TC500-B / Shimano TC500-MS-B
110x15mm width front hub
32 spoke holes
Centerlock
148x12mm width rear hub
32 spoke holes
Centerlock

RIM
MERIDA COMP TR
29mm inner width
material: aluminium
Tubeless ready (tubeless tape and valves not included)

TYRE FRONT
Maxxis Dissector
29x2.4"
fold
TR EXO 3C MaxxTerra

TYRE REAR
Maxxis Forekaster
29x2.4"
fold
TR Dual

AXLES
MERIDA EXPERT TR

SPOKES
Double Butted Black stainless

APPROX. WEIGHT
15.2 kg
